2-1/2" PP Diaphragm Pressure Gauges
Specialized used in PCB/LCD, pump fluid filter, drinking-water equipment and chemical industry. With all in one case covered around in order to its unbreakable function and excellent efficacy of anti-corrosion.
* Normal Size:2.5" (63mm)
* Accuracy: Class +/-1.5%
* Ranges: 0/1~0/30 kg/cm2 (bar)
* Temperature: Ambient: Tmin = - 20 deg. C
Tmax = 60 deg. C
Medium:Tmax = 60 deg. C
* Standard Vision Connection: Standard internal thread 1/2" PT or other ranges
internally & externally.
* Measuring System: Bourdon tube element: Copper alloy Diaphragm: VITON
* Movement: Copper alloy
* Face: Aluminum, White graduation and black figures
* Pointer: ABS, black
* Housing: PP anti-impact, all in one
* Bayonet Ring: PP anti-impact
* Filling: Glycerine(99.5%): Silicone(option)
* Windows: Safety glass/Glass
internally & externally.
* Measuring System: Bourdon tube element: Copper alloy Diaphragm: VITON
* Movement: Copper alloy
* Face: Aluminum, White graduation and black figures
* Pointer: ABS, black
* Housing: PP anti-impact, all in one
* Bayonet Ring: PP anti-impact
* Filling: Glycerine(99.5%): Silicone(option)
* Windows: Safety glass/Glass
